CHIP

PN8080,PN8081,AP8012,AP8022,PN8136,PN8137,PN8141,PN8143,PN8145,PN8147

內部集成了脈寬調制控制器和功率MOSFET，適用于小功率離線式開關電源。該芯片提供了完整的智能化保護功能，包括過流保護，欠壓保護，過壓保護，過溫保護和軟啟動功能。間歇工作模式能夠降低系統(tǒng)處于待機模式時的功耗...
  • PN8080
  • PN8081
  • AP8012H
  • AP8022H
  • PN8136
  • PN8137
  • PN8141
  • PN8143T
  • PN8145T
  • PN8147
  • PN8147H
  • PN8147T
  • PN8149
  • PN8150
  • PN8149H
  • PN8149T
  • PN8161
  • PN8162
  • PN8165
  • PN8166
  • PN6661H
  • PN8173
  • PN8175
  • PN8177
  • PN8775P
  • PN8776
  • PN8777
  • P
  • 品  牌：芯朋微
  • 參考價：2.0       庫 存：9999
    • 產品描述：

    AC-DC(SSR)

    ProductCharacterSW
    Voltage    		Standby
    Power    		RDS(on)Adaptor
    Output
    Power    		Open Frame
    Output
    Power    		FrequencyPackageVDD
    Operation
    Voltage
    PN8080DC-DC converter200V<150mW1.5Ω6W8W100KHz-1.5MHzDFNWB4*4-8L/SOP87.6-16V
    PN8081DC-DC converter200V<150mW0.7Ω10W12W100KHz-1.5MHzDFNWB4*4-8L SOP87.6-16V
    AP8012HPWM converter800V<150mW25Ω6W8W45kHzDIP8/SOP89~35V
    AP8022HPWM converter800V<150mW14Ω10W12W60kHzDIP89~35V
    PN8136Low Standby-Power Off-line PWM converter800V<30mW9.5Ω10W12W115kHzSOP169~24V
    PN8137Low Standby-Power Off-line PWM converter650V<50mW6Ω15W18W60kHzDIP79~24V
    PN8141Low Standby-Power Off-line PWM Converter650V<50mW3.6Ω12W18W100kHzDIP79~29V
    PN8143TLow Standby-Power Off-line PWM Converter1000V<50mW14Ω6W/8W6W/8W60kHzSOP8/DIP79~24V
    PN8145TLow Standby-Power Off-line PWM converter1200V<50mW12Ω8W10W60kHzDIP79~24V
    PN8147Low Standby-Power Off-line PWM converter650V<50mW6Ω12W18W60kHzDIP79~24V
    PN8147HLow Standby-Power Off-line PWM Converter800V<50mW8Ω12W18W60kHzDIP89~24V
    PN8147TLow Standby-Power Off-line PWM converter1100V<50mW6Ω10W13W60kHzDIP79~24V
    PN8149Low Standby-Power Off-line PWM converter800V<50mW4.6Ω24W28W125kHzSOP129~23V
    PN8150Low Standby-Power Off-line PWM Converter800V<50mW1.6Ω28W35W125kHzSOP129~23V
    PN8149HLow Standby-Power Off-line PWM Converter800V<50mW2.5Ω18W30W60kHzDIP89~24V
    PN8149TLow Standby-Power Off-line PWM Converter1100V<50mW4Ω18W24W60kHzDIP89~24V
    PN8161Low Standby-Power Off-line PWM Converter690V<50mW3Ω18W/24W-125kHz(Max.)DIP8/SOP810~38V
    PN8162Low Standby-Power Off-line PWM Converter690V<50mW3Ω25W/30W-125kHz(Max.)PDFN5*6/SOP1210~38V
    PN8165Low Standby-Power Off-line PWM Converter650V<50mW0.5Ω36W-125kHz(Max.)PDFN5*6
    SOP8    		10~38V
    PN8166Low Standby-Power Off-line PWM Converter650V<50mW0.6Ω/0.3Ω36W /45W-125kHz(Max.)SSOP109~57V
    PN6661HLow Standby-Power Off-line PWM Converter800V<50mW2.5Ω18W30W60kHzDIP79~24V
    PN8173AC/DC Converter with Internal Self-Supply Circuit800V<50mW14Ω5W5W124kHzSOP7
    DIP7    		10~18V
    PN8175AC/DC Converter with Internal Self-Supply Circuit800V<50mW5Ω8W8W124kHzSOP7
    DIP7    		10~18V
    PN8177AC/DC Converter with Internal Self-Supply Circuit800V<50mW2.5Ω10W10W124kHzDIP710~18V
    PN8775PAC/DC Converter with Internal Self-Supply Circuit750V<50mW19Ω6W8W124kHzDIP7/SOP7/SMP75.6~7V
    PN8776AC/DC Converter with Internal Self-Supply Circuit750V<50mW13Ω7W9W124kHzDIP7/SOP7/SMP75.6~7V
    PN8777AC/DC Converter with Internal Self-Supply Circuit750V<50mW6.4Ω8W10W124kHzDIP7/SOP7/SMP75.6~7V
    PN8778AC/DC Converter with Internal Self-Supply Circuit750V<50mW4.6Ω10W12W124kHzDIP7/SOP7/SMP75.6~7V
    PN8779AC/DC Converter with Internal Self-Supply Circuit750V<50mW3.7Ω12W15W124kHzDIP7/SOP7/SMP75.6~7V
    PN8770AC/DC Converter with Internal Self-Supply Circuit750V<50mW2Ω15W20W124kHzDIP7/SOP7/SMP75.6~7V
    PN8192CAC/DC Converter with Internal Self-Supply Circuit800V<100mW22Ω4.5W5.5W124kHzDIP75~7V
    PN8700High performance Multi-mode AC-DC Controller1700V<75mW1.0Ω36W45W85kHzDIP79~37V
    PN8712HFixed Frequency Multi-mode AC-DC Controller800V<50mW2.8Ω15W20W125kHz 100kHz 60kHzDIP711~24V
    PN8715HFixed Frequency Multi-mode AC-DC Controller800V<50mW0.5Ω40W42W125kHz 100kHz 60kHzSOP12/DIP711~24V
    PN8732AC/DC Converter with Internal Self-Supply Circuit800V<100mW2.8Ω15W20W100kHzDIP75~7V
    PN8733AC/DC Converter with Internal Self-Supply Circuit800V<100mW4Ω18W24W100kHzDIP7V
    SMP7    		10~29V
    PN8783PWM Converter650V<55mW0.165Ω65W90W500kHz(Max.)QFN6*88V~58V



    ProductCharacterStandbyPowerStart-up
    Current    		VDD
    Operation
    Voltage    		Vcc_ClampOutputPowerFrequencyPackageNote
    AP8262PWM Controller<500mW 200uA7.6~34V40V<100W 500kHz(Max.)SOP8
    AP8260QPWM Controller<0.2mW1.5mA3.5V~40V-<1A100kHz~1MHzSOP8&MSOP8xx3478
    AP8262CPWM Controller<500mW200uA7.6~34V40V<100W 500kHz(Max.)SOP8xxx28C42/3/4/5
    AP8265            PWM Controller<100mW 4uA8.5~26V40V<200W 200kHz(Max.)SOP8
    AP8267           PWM Controller<100mW2uA8~26V27V<70W65kHzSOT23-6-
    AP8268            ?PWM Controller?<75mW?2uA?10~26V30V?<70W?65kHz?SOT23-6-
    AP8270            ??PWM Controller????<100mW?            4uA?10~26V?            ?28V?            ?<70W?            ?????100kHzSOT23-6-
    AP8271PWM Controller <100mW4uA7.5-26V28.5V<100W100KhzSOT23-6-
    PN8272PWM Controller <50mW ﹣3mA9~35V40V<120W 65kHzSOP7HV Start-up
    PN8273            ??PWM Controller????<50mW?            ﹣1.5mA?10~40V?            ?40V?            ?<120W?            ?????65kHzSOP7HV Start-up
    PN8275            ??PWM Controller????<50mW?            ﹣1.5mA?10~40V?            ?40V?            ?<120W?            ?????65kHzSOP7HV Start-up
    PN8211PWM Controller <50mW﹣1.4mA8~57V60V<200W 110kHzSOP7
    PN8212            PWM Controller <50mW﹣1.0mA9~57V60V65W200kHz(Max.)SOP7HV Start-up
    PN8213PWM Controller <50mW﹣3mA9~56V60V<150W 500kHz(Max.)SSOP10
